    Rapid Ref : 803084

    HMT RTQ40 Low-Profile Magnet Drill 803084

    Prices From £872.00 ex VAT
     Buy in 3 easy interest free payments of £35.19 with
    Select Option

    The new HMT RTQ40 is a low-profile Magnet drill for tight access applications and is designed to fit into any space greater than 180mm. Suitable for use with any standard broaching cutters while optimised to work with the high-performance CarbideMax 40 cutters. Each machine comes in a plastic case with hex keys, a safety strap, a ratchet, and a removable coolant system.

    Features

    • Ratchet drive can be mounted on either side of the machine
    • Powerful motor and magnet gives excellent stability
    • Quick-change 19.05mm 3/4" Arbor for all standard broaching cutters

    Product Details

    Specification

    CUTTER SIZE RANGE  12-40mm
    MAX CUTTER CAPACITY   40mm
    TWIST DRILL CAPACITY 13mm
    LENGTH 310mm
    WIDTH 135mm
    HEIGHT 180mm
    STROKE 40mm
    WEIGHT 10.8Kg
    MAGNET (LxWxH) 160x80x37mm
    MAGNETIC FORCE 1200Kg
    MOTOR POWER 1050W
    TOTAL POWER 1100W
    SPEED RPM (No Load) 700RPM
    SPINDLE 19.05mm 3/4" WELDON
    TAKES CHUCK No
    COOLANT SYSTEM GRAVITY OIL FED



    Brochures & Manuals

    BROCHURES & MANUALS
       HMT RTQ 40 Operating Manual
