Technical Specifications
Input power: 230V 1Ph/50-60Hz +15% /-10%
Rated output current/duty cycle (230Vac – MMA)*: 200A@10%
TIG output range (230Vac)*: 15-200A DC
MMA output range (230Vac)*: 15-200A
Fuse size: 16A (25)*
Lift TIG open circuit voltage: 76 V DC (Lift TIG)
MMA open circuit voltage: 84 V DC (MMA)
Power source dimensiosn: 299 x 128 x 215mm
Protection/insulation class: IP21S
Power source net weight: 3.5kg
* When welding with maximum current I2>160A replace input plug with one>16A.
